  • Latest Software Upgrade Update For D9500 D5000 Smart Card HF NFC RFID Quality Inspection Machine & Encoding Machine
Latest Software Upgrade Update For D9500 D5000 Smart Card HF NFC RFID Quality Inspection Machine & Encoding Machine

Latest Software Upgrade Update For D9500 D5000 Smart Card HF NFC RFID Quality Inspection Machine & Encoding Machine

    • Automatic RFID encoding machine is programmable & durability

    • RFID/NFC reader buildin for different kind of label encoding

    • Customized Reader function is supported to the needs

    • RFID/NFC encoding facility capacity up to UPH 9500pcs/hour

    • Auto Ink/Ribbon Marker or replace defected label for rejection

    • Easy operate,Friendly Interface,Touch Screen & Mechanism Button Control

  • DataSheetSend Enquiry

Latest Software Upgrade Update For D9500 D5000 Smart Card HF NFC RFID Quality Inspection Machine & Encoding Machine

  • Function Test (without  encoding machine)

    please run the software with parameter "-develop" so the shortcut of execute name will be finally like "$driver name/folder name/CodeMachine.exe -develop


    Remark: Driver name, Folder name is different depends on computer/pc, key point is the content with RED color, also, please make sure don't use any HF & UHF as a protocol from this software, in case you have that reader it will work properly, this parameter of "-Develop" will give command to run program once in each second in case of no real machine is connected.


  • How to Update Encoding Software?

    Latest software pack is support to universal machine IVF-D5000/D9500 basing on operation system Microsoft windows 7/8/Vista/10 (Windows 2000/XP is no longer available)


    Encoding Software is green package, don't need to re-install again, request to just overwrite those updated files


    Step 1: Download Upgrade file from website and move file to "Desktop" of encoding machine

    Step 2: Unzip the Upgrade files into a new folder from encoding machine

    Step 3: Goto this new folder and Delete "Config.XML", "Config2.XML" and "Log.mdb" 3 files

    Step 4: Select & Copy all the new files including sub-folders from this folder

    Step 5: Goto "My Computer\My Documents\RFID Encoding Machine\"

    Step 6: Execute "Paste" and "overwrite" all existed old files.

    Step 7: Reboot computer of the encoding machine for new update

    Step 8: Verify & Finish


  • Be careful of the important files and do not overwrite the files(folders and files are listed below for your consideration) that you had more concerns, especially don't allow to overwrite machine existed "Config.XML" & "Config2.XML", otherwise it will cause your machine totally doesn't work since all exist parameters are defined to meet your machine device."Log.mdb" is connected to your machine production record either quality readcheck or write process

    \Data\         Those data files are required for Plug-in software including sub-folder defined

     \Database\   *.TXT  was required to be put in this folder for the Database files loading

    \Filter\      *.txt are required to be put here for Filter purpose during machine operation,

                     in order to kick out or save appointed tags.

    \HF\          HF Reader API Lib

    \UHF\  UHF Reader API Lib

    \LOG\  When config log is enable, all operation from machine will be recorded

                      into a Log file with current day & real time

    \Report\    Production reports for each tag/label which is related to appointed Plug-in



Update History(Latest in 2022):

2022-02-22 1) improved plug-in of "RL863-FM13HS01初始化" 2) fix bug the pop-up windows redirection issue on plug-in of NDEF format considering the URL without "www"

2022.02.19   concerning order & improvement request

1) add reader protocol for "RL863-READER-Ultralight"

2) Add plug-in "RL863-Ultralight-NFC" to solve issue the failure rewrite on EM4423 of "530UE-Ultralight-NFC", operation was same to "530UE-Ultralight-NFC"

3)Fix NFC writing bug to the URL without "www" cause to no popup redirection issue

2022.01.24  Add Un-lock function from "288D-General-DataWrite" with same process.

1) database has no TID field, un-lock process follows line by line,  database has TID field, un-lock with proceed also unlock TID

2) During Un-lock process, don't checked on "Write Tag"

2022.01.23 Seperate "DATAPROCESSOR数据处理" the "Enable Config & Filter Non-Hex" to be two option in the setting;  improve the manual input of Barcode popup windows-2021.12.8 for better operation to avoid the un-used record for missing rejection



[Update in 2021]

2021.12.22 Add new plug-in "530UE-15693-NFC with same function to "530UE-Ultralinght-NFC" support URL、TXT-en、TXT-EN and so on NDEF program encode.

2021.12.8 beauty the popup windows of manual input on Barcode, select "yes/是" for rejection (export 24digits of 0 in report and ignore quality inspection process ) and "N" for barcode manually input.

2021.11.1 move setting "set newpassword" from protocol of "HF_Ultralight_530UE" to plugin "530UE-Ultralight Report";  2 enable "Lock_page" function to "530UE-Ultralight Report", allow set lock 0-4, more details see "lock page对应位置详细芯片NTAG213_215_216 V3.2.pdf" 资料里的8.5.2 Static lock bytes (NTAG21x)

NOTE: Program flow - write page data -- lock page -- set password

2021.07.26 Add plug-in "288D-VBL Temperature Tag”for the testing of VBL sensor tag; plug-in qualify setting for temperature range;  each tag will read 3 times to qualify for good, any one reading out of range will be NG;  report including each time or Temp, N, Tune-A, Tune-B and Tune-C, Log format:

Time, TID, EPC, CODE, A, B, C, N Value, Temperature, Result

2021-09-03 10:32:50, E2C19CB140005825847500253B77072A, 000000000000202105180580, , 5997, 24238, 8024, 0x01F5, 26.14℃, 0x01F5, 26.14℃, 0x01F5, 26.14℃, OK

 2021-09-03 10:32:58, E2C19CB140005825847500253B36072A, 000000000000202105180581, , 849, 17889, 5134, 0x01BA, 26.07℃, 0x01BA, 26.07℃, 0x01BA, 26.07℃, OK

2021.05.06

1) Fix the step bug in setting of "DataProcessor处理"

2) Change Barcode export log in original reading to the plugin of "288D-General Report", "288D-FASTAG-NEW", "M6E-General Report"

2021.04.30

1) modify UI setting for "DataProcessor", "DataBase界面" and preview "Database for ready data program"

2) in the setting "DataProcessor/数据处理" 14th, change checking length from Bytes to Digits(ignore Bytes calculation)

3) Reset the step value from "DataProcessor" while changing files

2021.04.28 Improve plug-in "RL863_FM13HS01初始化", improve how to create random keys

2021.04.17 Combining function together for total UI change including Auto, Scanner, Database, Camera, config setting and so on, details to“20210417 编码机软件升级更新——DataProcessor数据处理.docx”

1) plugin "Andi_RL863-FM13HS01" changeto "RL863_FM13HS01初始化"

2) Move checker of "UID(else block) of HF" to the protocol of HF_14443A_530UE、HF_15693_530UE and HF_Ultralidht_530UE

3) combine "Other DataProcessor配置" and "Auto DataProcessor配置" into new setting as "DataProcessor/数据处理"

2021.04.15

1) add new reader protocol "安的RL863读写器"

2) add plugin of "FM13HS01标签初始化" for  NFC NDEF, mirror UID and secure access, lock data

3) plugin generate 2 reports, one is for client (UID, KeyA, KeyB, Fx), another one is for production itself (date-time,UID, KeyA, KeyB, Fx, URL, result)

2021.04.12 update NFC 2 NFC plugins to the protocol of reader 530UE, enable scanner of DataSource and fix report with completed of URl such as http://  and http://www.  ,  setting "Class" as "none","Content" as empty

2021.02.05   华大行标读写器 清点完标签之后进行睡眠,防止读写器存储数据较慢导致下次清点时使用上次的清点结果;


[Update in 2020]

2020.12.10 improve the plugin of "288D-General-DataWrite" removing cache sourcecode

2020.12.08 update plug-in of "288D-General-DataWrite"

1)write error will retry 3 times, in case of still fail for rejection output.

2)add "read tag test" option with production log including TID/EPC/USER

3)cancel the requirement of 2020.12.01开发的功能 "288D-General-DataWrite"插件增加最小读启动功率测试,写码成功后再走一次读标签动作。实现写码和性能检测一起操作,提高生产效率。

4)write successful will run read once for qualify check, write parameter will load the first line of reader setting, read parameter will load the 2nd line of reader setting.

2020.12.02

1) Add plugin "NULL-外设辅助发行" with "External Output" to Combine Voyantic TS tester for rolling RFID test, and return back result to the IN4 port of TS device. while“IN4”in HIGH, output PASS signal, while "IN4" in LOW, output NG signal

2) Add "External output" from plugin of "RH11-15693"

3) add setting parameter "external output timeout(ms)" and "external output time(ms" to the XML file "config2.xml"

2020.12.01 improve "FM13DT160 temperature sensor tag inspection"  considering reader "RL863", function request including initialization, start measurement, stop measurement, read measurement, read voltage

2020.12.01 add function to "288D-General-DataWrite" with minimum read power test. while write command is successful will perform one more time of reading for qualify check.

2020.11.27 fix bug for error notice "barcode value error" while plugin "288D-FASTAG" is in use with Barcode scanner. modify barcode filter rules to have 16digits.

2020.11.23  add new protocol "18000-6B" to "288D-General Report" for TID read only, remain other functions for no change

2020.11.12

1) change plugin "288D-FASTAG" in order to meet TIPPS certificate from new https

2) add "tamper check" from plugin "530UN-Config43N1F"

2020-11-12 Update Postman tool for supporting new API/SSL to Plugin"288D-FASTAG"

2020-10-17 Plugin"288D-FASTAG" compatible for barcode either with or without sympol -

2020-10-15  Add "Null-external reader"外挂读写器 make any external reader to work together with encoding machine possible, walkthrough is to lisen "ctrl+0" keyboard simulator and perform material feeding automatically

2020-10-15"288D-FASTAG" compatible to more Vendor code except "05", revised generation rule for EPC, reduce one digit of "Pre-Code EPC" to be 16digits, Take centre number of original barcode to adjust EPC

2020-10-15 Re-allign sequence of "Plug-in" from letter small to higher

2020-09-28 add new reader protocol and plugin for "Quanray QR4451"

2020-09-21 LED light plugin for RH11-15693 protocol, 用于飞聚标签亮灯验证

2020-09-10 增加华大国标(行标GB protocol)读写器和插件, compatible to fix bug for upper/lower letter input by new 2D Barcode scanner

2020-09-05 Plugin "NXP 424DNATT" Tamper function

2020-07-13 plugin"RH11-Ultralight" NG condition revised to continously inventory failure for 3times

2020-07-11 plugin"530UE-Ultralight Report" add security coding part for "NTag21X",Protocol of RH11 Reader and plugin"RH11-Ultralight" add new file"CP210xRuntime.dll" for "HF"文件夹新增"RH11"

2020-07-04  plugin"530UE-15693 Report"/"530UE-Ultralight Report" fail to write without UID report

2020-07-03  Plugin"530UE-15693 Report"/"530UE-Ultralight Report", write mode export also report with UID and Block data, Plugin"530UE-Ultralight-NFC"/"530UN-Ultralight-NFC" report including UID

2020-04-29 Fix bugs of popup notice during NG founding

2020-04-20 During the scan of "barcode", display NG for notice and auto input 24digits of 0 for NG program itself;

2020-04-18  UHF288D Reader Protocol add "CRC verification error to reboot device automatically"

2020.03.05 Support Dot Netframe update from Net 4.0 to Net 4.5

2020.03.05 Support Plug-in using HTTPS as new URL for encoding for "288D_FASTAG",which requires Net4.5

2020.03.05 Unreadable case of "Camera/ Scanner" will appear new interface with NG and INPUT new selection

2020.1.20 Enable "Query" Function in case of machine is running, in order to help operator access processing history

2020.1.20 Appear"Roll Number" as new human interface input for the plugin "288D-General report /Fastag/fastag2/fastag3/Fastag-new", in order to prevent operation mistake, and roll number will be named directly into the beginning of report Filename.

2020.1.20 Change input/output filename from TXT to CSV for the plug-in "Fastag-New" & "FASTAG"

2020.1.6 Change Plugin "288D-General-Data-Write", allow one more data "TID" in the database with format TID: E2001234567890123456,  inventory command for current tag and search associated TID content for full encoding, otherwise do sequence encoding following the database

2020.1.6 Reader communication fail with handle error notice because of defected tag with TID unreadable and EPC readable and resulting next all pieces rejection, reconnecting reader won't solve the issue, followup demo sourcecode, set a delay of 1000ms between close and new open, also inforce value -1 to the handle.

2020.1.1 while multiple bad tags were founded from 288D-FASTAG2, error occur "sucess" means "0" answer out of range"No Tags", reconnect reader to clear buffer memory, in order to prevent mismatching issue between barcode & TID, before scanning make barcode as null

2020.1.1 under new description to provide 2 reports for each production which they are full-report and report, allow screen input & database loading for userbank

2020.1.4 add new plugin of 288D-FASTAG3 with default VC & Plate No as null and disable input from screen

Related Download -Latest Software Update Smart Card HF NFC RFID Quality Inspection Machine Encoding Machine

Presentation e-Catalogue Case Studies

[Update in 2019]

2019.12.24 Change report file format from TXT to CSV at Plug-in 288D-FASTAG2, add new function of "start RF-power" from "288D-PC-Performance Test", and while NG for 10times do re-connection to the reader, enable to save parameters setting

2019.12.28 block remote connection of "288D-FASTAG" while barcode is unreadable, but output "FAIL" to ignore further process which it will stop software.

2019.11.23 Fix missing Filter function in Read operation of plugin "M6E-general-report", allow barcode report in both of original scanning & dataprocessed for "M6E-general-report" & "288D-general-report"

2019.11.30 Modify plug-in 288D-TamperCheck in order to write & quality at the sametime by using 2 RF powers

2019.11.12 Update Plugin "288D-FASTAG 2",Write model cancel the data loading from PlateNo and loading data from consigned TXT file only. 写码时不再调用插件里屏幕数据VC和Pre-Code直接调用客供TXT数据,同时界面上划个横线DISABLE

2019.11.12 Add New Plugin "288D-FASTAG-NEW" For new FASTAG encoding & quality check in order to match QR-code & TID and injection data under consigned TXT

2019.11.22 Fix bug of the plughin 288D-FASTAG2 & 288D-FASTAG-New, in order to remove VC come to usermemory

2019.11.22 Change popup notice "Bad Tag is Detected", & add more column of "UserMomery" into report of plugin "288D-general-report" & "M6E-general-report"

2019.11.08 Add new Plugin "288D-PC-Performance Test" with upper and lower performance limit control,remove best & worst tags 用于标签一致性卡控(性能不良卡掉,性能太好也卡掉)

2019.08.13 Update reader firmware to be V0.62 of UHF 288D in order to measure UHF temperature tag and fix several bugs for tag locking 读写器固件版本更新支持温度测量修复V0.50版本密码00000000无法lock的BUG

2019.07.01 Add Plug-in "UHF_GB_HD16R01URM" GB protocol 协议

2019.05.11 Update reader firmware to be V0.50 of UHF288D 读写器固件版本更新为:V0.50

2019.04.10 Bug fixed for 2019.03.04 update, to solve the NDEF Content wring data can't be recognized by NFC cellphone.写入数据格式不对,NFC手机读取标签后无法显示正确的文本数据

2019.03.04 Update "530UE-Ultralight-NFC/530UE-14443A-NFC",while select "Type=TEXT-en or Type=TEXT-EN, write data (OTP0-OTP3) changed from "E1 11 16 00”to "E1 10 06 00"


[Update in 2018]

2018.12.11 Update "M6E-Brazil_ETC" "IF2-Brazil_ETC" to support latest chip EXB2014B2, cancel partitial TID program 以实现对新芯片EXB2014B2的支持,取消部分TID编码

2018.12.11 Update the language support for all pop-up windows in both Chinese and in English "setup/config/protocol/plug-in" 内出现的中文提示框 进行中英文双语显示,减少不必要的技术支持

2018.12.11 Add new Plugin"530UE-15693-DES", UID convert to DES and write into page0-4 换算成DES算法写入

2018.11.30 Update Report output with additional Surface Number for the Plugin "530UE-Ultralight Report/530UE-14443A Report/530UE-15693 Report"日志里增加表面码

2018.11.30 Update Plugin"华大定制插件" Camera scanning to be qualified from remote server and generate report 表面二维码通过摄像头识别,发行数据是将二维码数据发给服务器来获取的。日志中增加表面二维码数据。

2018.11.19 New Plugin for 14443A with Key A and Key B both encryption增加插件-F08芯片数据写入和A B密码加密.

2018.8.31 plug-in "530UE-Ultralight-NFC", "530UE-14443A-NFC", "530UN-Ultralight-NFC extended "EN" type to be 2 options "EN" and "en" both

2018.5.23  1) plug-in "530UE-Ultralight-NFC", "530UE-14443A-NFC", "530UN-Ultralight-NFC" was included more NDEF protocols except URL type, Lock Tag was made with an extra option for selection.  2) Plug-in "M6E-HGS" was created for DLL loading file "libtagCreateLib_21052018.dll" in order to generate TAG UserData, AccessPassword according to related tag TID & Barcode number. Operation Code is confidential.

2018.3.30  Add 4 new plug-in as below, especially for single piece of rfid/nfc tags, with real counter function, means same TID/UID/EPC, counter will just count qty for 1time even though more than 1 time inspection for same piece of tag, plug-in has unique piece of report function buildin also, real seperation qty setting is configed from plug-in itself. 增加4个插件,插件的功能是用于统计片状标签的实际合格数量,插件带有日志输出功能,当选择插件时在主界面上会跳出一个弹框,弹框里显示“Real Counter”数量,当软件读同一片标签不管成功多少次,在Real Counter及插件日志里只仅记录一次计数或数据

--530UE_14443A_Real Counter

--530UE_15693_Real Counter

--530UE_Ultraglight_Real Counter

--288D_Real Counter

2018.3.23 Plugin of "288D-TamperCheck", if EPC reading at offest 0x20 got fail, will make retry 3times, in order not to missing good tags. 如果读不到数据就重新读,三次都读不到数据才输出坏标提示

2018.3.22  1) plug-in "288D-TamperCheck", using barcode as DATAsource, put barcode data into report also,  fix in "write" operation method of, TamperCheck judgement is revised as "0040 is tampered, other data is un-tampered",  if barcode is ="00000000" (eight piece of 0), QC result = Fail, add fail history also into report  2)Fix bug for Camera - DataSource, "Pause" operation will transfer last history to current record.  Clear memory buffer / cache not to transfer data to next record any more. which is as same as the barcode - DataSource. 3)Plugin of "288D-MVM-ETC" , add more input frame for the new report requirement, like "Pack No/Carton Box", seperate each column to be two columns, fix repeat counting issue.

2018.3.2  plug-in "288D-MVM-ETC" report format was changed in order to fit packing purpose, PackNo and CartonBox both allow more letters for report generation. put more other data into specified report.

2018.2.10  1)288D-MVM-ETC fail encoding was added into report,barcode 00000000 was defined as fail encoding to ignore/skip printing issue更新坏标处理方法, 2)Improved production capacity for the Camera Datasource摄像头提速

2018.2.2  New plug-in of 288D-MVM-ETC(ETC Application)-SAM CARD Encrypted Encoding, Add CSV format of output report into plug-in of 288D-General-DataWrite

2018.1.19  1)288D-General-DataWrite add new function of LOCK and PermaLock for EPC,User and reserve,Lock process is after writing process 功能选择LOCK,288D-TamperCheck好坏判断修复——8084、C040、4040为好标,0040为坏标 EPC(0x20)=0080/C040/0040=Fail, 8040=OK, revised to be: 0040=Fail,8040/C040/4040=OK   2)288D-General-DataWrite-- Add Lock & PermaLock function

2018.1.19   add new DataSource from"Camera" created in main menu and "Setup", in order to collect QR-code,1D/2D Barcode automatically, also quality inspection for label visual check by machine增加camera采集功能,实现1D,2D Barcode,动态采集自动识别


[Update in 2017]

2017/11/28 New encoding algorithm for FASTAG plug-in

2017/9/25:  1)allow plug-in 华大定制发行服务 repeat program tags  2)bug fix for UHF288D-general-report, in order to correct EPC and TID  confused because of communication error, re-connected again if error found

2017/9/25 1)allow plug-in 华大定制发行服务 repeat program tags  2)bug fix for UHF288D-general-report, in order to correct EPC and TID  confused because of communication error, re-connected again if error found

2017/9/4 Major window interface increase information width to be 4 lines,allow to indicate more status from machine program and inspection; UHF288D procotol has increase one more selection to maximum support 4 antenna, means each transaction will program/inspect more than 1pcs of tag or label, to enhance capacity from 1 to 4, means 4 times capacity and 4 times of web size of the labels (4pcs labels parellelly )can be program/inspect from this machine, Related UHF288D-General-Report is also improved to support 1-4 pcs of tag in every report line. seperation as same as previous design.  1) UHF288D读写器协议修改3行为4行,允许多排标签顺序轮流检测,同时增加界面配置Ant1,Ant2,Ant3,Ant4,勾选几个则执行几次读写操作,窗体显示框内用分号隔离

TID1:xxxx;EPC1:xxxx;TID2:xxx;EPC2:000

UHF288D-General-Report插件修改,报告格式每行显示多个记录如TID1/EPC1/TID2/EPC2/2017/7/4华大定制发行服务---烟草new plugin

2017/8/28: Confirm the Enable function "OtherDataConfig" is for filter and function setup both

2017/8/11: New Plugin for ciggaret 华大SM7发行服务new plugin

2017/6/13  improve the plugin of FASTAG/FASTAG2 to get visible Pantone Color from main window with FLASH light the Image of Pantone Color in every 2 seconds, prevent mistaken of the VC wrong typing.   exception of initialization EPC 96 and 128bits for 3 readers UHF288D/2204/M6E, Allow to init EPC bank length from config2.xml file. EPC init length can be any times of 32bits, so they will be 64bits, 6bits,128bit,160bits,192bits,224bits,256bits, 288bits,320bits,352bits,384bits,416bit,448bit,480bit,512bit and so on

2017/6/12  Thingmagic M6E Reader is able to connect with Encoding Mahince with Fixed frequency & HFSS frequency, Reader M6E human interface with scroll bar to allow display all infos.

2017/6/12   Change plugin name from IF2-Intermec to IF2-Brazil-ETC, Add new plugin named M6E-Brazil-ETC, Add new plugin named M6E-General-Report, Change plugin function of M6E-brazil-ETC to show both of EPC and TID from main window, Correct Fail report inside of M6E-Brazial-ETC plugin, without space between data columns.

2017/3/18  Plugin of "FASTAG" judge fail label by a new condition rule as it's right digits = "0000000" insead of 15 digits 0 typed and  more efficiency

2017/3/18  Plugin of "288D-General DataWrite" increased,  under DATABASE public function, to select data for general datawrite, the data file will be TXT format and the data was specified in a certain rules as below listed which can include EPC, USER, RESERVED or just one of them and there is no sequence required, each line will be wrote into just one tag, one by one followed, and one by one programed by automatically. For example(Bank name+":"+"Data"):


Program EPC--> EPC:Data-information;  (with bank name &  ";" seperation)

Program USER--> USER:data-information;

Program RESERVED--> same process

support multiple bank and different memory Banks just with seperation ";"

E.x "general-file.txt" located in "Driver D" ready for program

d:\documents\rfid_encoding\Database\general-file.txt


EPC:3159AFB9010001FF01000114;

USER:13020001FF010002B9AF5931;

RESERVED:00100003

EPC:3159AFB9040001FF0100040D; USER:0D040001FF010004B9AF5931; RESERVED:00100004

USER:0E030001FF010003B9AF5931; EPC:3159AFB9030001FF0100030E; RESERVED:0010004

EPC:3159AFB9040001FF0100040D; USER:0D040001FF010004B9AF5931; RESERVED:00100004

RESERVED:00100004; EPC:3159AFB9020001FF01000213;


2017/3/6  Plugin of "288D-FASTAG" increased one more function to both support  the barcode number including"-" or without"-", and judge fail label by a new condition rule as it's right digits containing "0000000" insead of 16 digits 0 typed and  more efficiency, Plugin of "288D-FASTAG2" , judge fail label by a new condition rule as it's right digits containing "0000000" insead of 15 digits 0 typed and  more efficiency

2017/2/27  New Plugin of "530UE-Ultralight-Tagcopy" is added, according to requirement of multi-block data write(Read function is not applicable), prepare one TXT files including all of information similar to below sample listed,  and selected for encoding write process,  each line inside the TXT file contains HEX offset Page/Block address, seperate sympol":",  BlockData for this offset, all digits are HEX format except ":" If writing data contains password block, the data should be place in last line, otherwise will cause writing fail or return error.

----Sample Data inside TXT file-----

04:0335D101

05:3533036E

06:66232E33

07:31357968

08:38273133

09:38742341

29:E0000CFF

2A:10000000

2B:00000000

2017/1/10  Exchange function between "Write only" and "Lock Only" from plug-in of FASTag and FASTag2 to be fixed, disable Internet connection to speed up the UPH while machine running in "lock Only" mode.

2017/1/9   Added new function of "Filter过滤器" which is Barcode filter, and change display to understand more for operator. support both of Read and Write mode. 功能中增加Barcode  Filter,在SCANNER源头处增加, 同时支持READ或WRITE双模式下可过滤,新流程规则为" Scannner  ->Filter->DataProcessor-"Read/Write"

2017/1/2   Added new Plug-in"288D-FASTAG2", most are same with FASTAG, loading database as program DataSource. Read to generate report for customer, Write and generate final report for program purpose. 类似原插件Bolivia车标插件,读功能时生成数据库,然后由此数据库客户提供加密加密并写入到EPC和USER区,之后判断插件是否需要PermaLock或仅仅是Write  Only操作, 具体按照"20170109 UHF288D-FASTAG2插件要求-分读和写2个功能.zip"


[Update in 2016]

2016/12/28  New Changes for the Plug-in Kit of "288D-General Report" increased one more Barcode column as a general report, support Read and Write both mode.增加一个判断(Read/Write均判断)使用Scanner做为SourceData时, 日志中增加  Barcode字段(原始采集数据),非Scanner的SourceData不增加Barcode字段

2016/12/28  New Changes for Plug-in kit of "FASTAG" 插件,界面增加如下选择判断:  there are some options for choose " Write&PermaLock, PermaLock Only and Write Only"  1) Lock Only = EPC  PermaLock-->User PermaLock-->KillPassword PermaLock  2) Write & Lock =  EPC+user plus " PermaLock EPC+USER+KillPassword  3) Write Only - just write "EPC+user"

2016/11/15  1)530UN-Config43N1F增加日志输出, 日志格式SN;Time;UID;Tampercheck;Result 不同容量选择地址位0x2A, 0x2A, 0xE4, 0xE4,0xF2不同,首2bytes ="00 00"是TamperCheck位回读一次, 判断TamperCheck="00 00"则为Untampered, Result=OK   2)新增插件288D-TamperCheck, 日志格式SN;Time;TID;EPC;TamperCheck;Result   , TamperCheck: EPC 0x20(hex),Count=1, 数值可能是0080/C040/0040, 判断TamperCheck=8040则Result=OK  "读功能"时读取TID,EPC及TamperCheck EPC并判断输出日志, "写功能"时按照"标准数据源DataProcess->ASCII结果"来写EPC,之后读TamperCheck EPC判断结果输出日志

2016/11/14 生产日志288D-General Report, 2204-Genenal Report等所有插件的数据处理的"写功能"均新增"数据ASCII码转换"功能并采用以下流程来完成, "DataSource(选择)"->"DataProcessor(数据处理)"-->"DataProcessor->ASCII(数据转换)",插件中"读功能"不经过"DataProcessor->ASCII"转换流程

2016/11/14 Rename Title from Software 修改名称:

Config/系统配置     --->Default Config/标准配置

DataSource->ASCII   --->DataProcessor->ASCII

Scanner Config/条码处理  --->Other DataProcessor/其它数据处理器

Auto Config/自动处理   --->Auto DataProcessor/自动数据处理器

新增Other DataProcessor数据库处理-->支持Scanner和Database双功能配置


1)Walkthrough changed 不良品处理单元 ---> 坏标重试(重试会生成坏标记录的问题)--> 需要把插件分为2部份(工程量偏大-->暂缓), 修复18K3M3协议在Win2K设备系统上无法使用的BUG,增加动态文件Irprops.cps,  fix 3 NFC plugins 修复NFC 3个插件日志时输出NDEF RECORD为文本字符

2)增加FASTAG插件, 不作远程服务器校对,"读功能"指读TID,EPC,USER,然后输出日志与"写标"相同,要求BARCODE原始数据增加-线(第6位后先加一条横线,含第一条横线第10位后再加一条横线)

例子: 6074170050008000  加横线后 607417-005-0008000

3)修改FASTAG插件, USER的"读功能"时ADDRESS和COUNT需要设置, USER区的"写功能"地址需要设置


2016/11/14 530UN-Ultralight-NFC\530UE-Ultralight-NFC\530UE-14443A-NFC三个插件, 均增加日志文件输出, 格式为SN; Time; UID; NFC Record; Result  **(上行为日志字段的标题栏,固定打印进去)

2016/11/11  Fastag插件增加一条判断规则(剔除条码扫描不良标签), 如果Hex_Barcode_SerialNo = “00000” 同样判断为Fail. Fastag plug-in added a rule to judgement (reject the bad scanning tag), if shwos " Hex_Barcode_SerialNo = “00000” ", means "fail".

2016/11/10 修改相关协议及插件名称 Changed relative protocol and name of plug-in

HF_14443A ---> HF_14443A_530UE

HF_14443B ---> HF_14443B_530UE

HF_15963  ---> HF_15693_530UE

HF_Ultralight --> HF_Ultralight_530UE

Ultraglight Report ---> 530UE-Ultralight Report

14443A红色经典 ---> 530UE-14443A红色经典

14443A Report ---> 530UE-14443A Report

15693 write test ---> 530UE-15693 Write Test

15693 Report ---> 530UE-15693 Report

15693 赖永初 ---> 530UE-15693赖永初

Ultraglight-NFC ---> 530UE-Ultralight-NFC

Ultralight-NFC-530UN ---> 530UN-Ultralight-NFC

14443A-NFC ---> 530UE-14443A-NFC


2016/11/10 发现2016-8-8更新的API接口"Ultralight V1.1-支持64块.rar"存在TID读取数据不对BUG,(数据page读写正常) 改用通讯协议的捕捉方法来实现,不用API接口. Dated on 2016-8-8 the update of API interface "Ultralight V1.1-支持64块.rar" has the bug which read that TID data wrongly ( read and write of data page is correct), use the capturing method of changing communication protocol instead of API interface.  修复BUG影响部件包括HF_Ultralight协议设置及插件. Repaired the effect of other parts by bug,includes HF_Ultralight protocol setting and plug-in.  Plug-in includes: Ultralight report, Ultralight-NFC

2016-11-9 Fix bug in Barcode function located in "Scanner Config", modify "disable" to be "enable",  Fastag Reports with "-" as barcode seperate sympol.

2016-11-8  new Plug-in of FASTAG for ETC program application updated

2016-10-23  1.Production Report generator automatic save in case of power lost, will just loose one piece of record for current tag, 2.changing NFC plug-in function in English version, 3.changing UHF reader debug software as a popular interface and default parameter configed in advance.

2016-09-28 288D加密功能添加参数“旧密码”;The encryption function of 288D reader is added to the parameter "old password";  RL863-EXAM插件添加参数“旧密码”;RL863-EXAM plug-in is added to the parameter "old password";

2016-09-22 288D新增加密功能;Added encryption function for 288D UHF reader;

2016-09-14 新增18K3M3读写器;Added 18K3M3 reader; 新增RL863-EXAM插件;Added RL863-EXAM plug-in;

2016-09-08 UltraLight协议换DLL;The Ultralight protocol changed to DLL;

2016-08-17 新增“Config_Tamper Check”插件;Added “Config_Tamper Check” plug-in;

2016-08-16 新增530UE动态库,替换Ultralight协议接口;Added 530UE dynamic library,replace Ultraligh protocol interface;

2016-08-03 合并吴智杰修改过的代码(凯路威插件);The modified code by Wuzhijie (Kiloway plug-in) is mergered;

2016/6/13:  UHF288D protocol increase "scroll bar" 界面中也需要调整加滚动条

2016-04-22 UltraLight的Offset范围加大到4-256;Offset range of UltraLight is increased to 4-256;


[Update in 2015]

2015-09-17 新增华大15693协议读写器;Added 15693 protocol for Huada reader;


[Update in 2014]

2014-12-16 赖永初插件读日志更新;Updated the reading log plug-in for Laiyongchu tag;

2014-12-15 赖永初插件日志补足12位;Plug-in log to make up 12 digit for Laiyongchu tag;

2014-12-12  过滤器增加Uid;Added Uid for filter at setup;

2014-12-10 统一日志输出格式;Unified log output format;

2014-12-05 15693读flag固定设置为0x02; 15693 read flad is fixed to 0x02;

2014-11-17 备注:过滤器目前只有一个UHF过滤器,在“UHF生产日志”里面用到;Note: the filter is only for UHF currently which will be used in "UHF production log";

2014-10-29  Add plugin of Intermec plug-in;

2014-10-22 1).巴西读写器天线改成2号;Brailian reader antenna is changed into No.2; 2).巴西读写器设置功率;Brailian reader power is setted;

2014-10-17 增加巴西读写器(UHF_Reader_V3); Added Brazilian reader : UHF_Reader_V3;

2014-09-19 坏标输出延迟,结束的时候弹出结果;Bad tag ouput delayed,shows the results when it is end;

2014-09-05  1).恢复坏标输出间隔时间配置 Restore the bad tag output interval configuration;  2).UHF读写器设置640kHz频率,速度提升4倍 UHF reader sets 640kHz frequency, speed is increased 4 times; 3).UHF读写器清点时间可配置 The inventory time of UHF reader can be configured; 4).坏标输出间隔配置上限调整 The limit configuration of bag tag

2014-08-30  优化控制全流程的时间参数,以实现产能优化,无延迟,保证每2条发送命令间隔达到20ms以上即可,GPO4开与关闭时间间隔调整至25ms, 否则单标签工作无法循环;优化读写器清点时间;Optimized the control parameters of the whole process,in order to achieve optimization of production capacity and no delay, to ensure that every two commands can be sent more than 20ms, the time of GPO4 opening and closing is adjusted to 25ms interval,or single tag can not be worked in cycle;Optimized the inventory time of reader ;output interval is adjusted;

2014-08-29  增加华士读写器GEN2 V2接口;Added the reader Gen2 V2 interface;

2014-08-05  A-过滤配置支持多内容过滤,过滤内容用逗号分隔开;Filtering configuration supports multiple content filtering,the contest of filter is separated by commas; B-插件“UHF日志”添加过滤功能;Added filterfing for plug-in "UHF log";

2014-07-04  增加Epc96BitInitialization插件;Added Epc96BitInitialization plug-in

2014-06-27 增加UhfInlay插件;Added UhfInlay plug-in

2014-06-17 Ultralight 输出文件夹--改名: 阿弗艾德 --》Ultralight ; Ultralight output folder-renamed: Afford-Ultralight;

2014-06-14 日志文件路径可配置;Log file path can be configured;

2014-06-12  坏标弹窗提示,跳标、停止二次确认;Bad tag tip window, "Jump" and "Stop" for second confirmation;

2014-06-09  超高频读写器的IP地址放入配置文件;Put the IP address of the UHF reader into the configuration file;

2014-06-03  修复0428版本引起的HF_UltraLight清点标签长度判断错误;Repaired  the HF_UltraLight invenroty tag length of error determination which cased by 0428 version;

2014-05-23  坏标提示窗口,去掉“跳标”、“停止”按钮;Bad tag tip window,removed the button of "Jump" and "Stop";

2014-04-28  修复上一个版本修改之后,产生的14443A协议清点Bug;Repaired the 14443A protocol inventory bug in previous version;

2014-03-26  增加HF_UltraLight清点结果长度判断,不是7个字节抛出异常;Added the inventory result length judgment of HF_UltraLight;

2014-02-26  增加HF_UltraLight配置界面;Added the interface configuration of HF_UltraLight;

2014-01-17  增加标签过滤环节 Added the tag filter configuration,  标签协议下拉框增加“标签过滤配置”; In the tag protocol drop-down list, added tag filter configuration;

2014-01-13 允许断号:检测到坏标,屏幕提示“坏标”,输出GPO3,执行坏标计数,总数计数,并等待GPI3确认输出后结束当前循环; Allowed number: Bad tag is detected, the screen shows "bad mark", output GPO3, execute bad count, then total count, and wait for GPI3 to confirm the output and ended the current cycle.

2014-01-13  修改流程逻辑 Modify the process logic, 不允许断号:检测到坏标,屏幕提示“重试”和“跳标”,如果选择“跳标”则输出GPO3,执行坏标计数,总数计数并结束当前循环,如果选择“重试”当前标签读或写动作,测试结果是好标,则输出GPO2,执行好标计数,总计数并结束当前循环; Disallowed number: when bad tag is detected,screem will display "Retry" and "Jump". If "Jump" is selected, GPO3 will be output, the bad tag will be counted, the total count will be counted and the current cycle will be finished. If selected to "Retry" the current label read or write action, the test results are good, the output is GPO2, the implementation is good standard count, the total count will be counted and the current cycle will be finished.

2014-01-10  赖永初插件,日志文件可以选择生成固定一个或者多个,固定日志为log.txt;Plug-in for Laiyongchu tag, log file can be chosen to generate fixed one or more,fixed log for log.txt;


[Update in 2013]

2013-12-11 赖永初插件,写标之前暂停一会 Plug-in for Laiyongchu tag, pause for a while before writing;

2013-12-06 赖永初插件,显示一行十进制 Plug-in for Laiyongchu tag,shows a line decimal;

2013-12-05 增加选择UHF区域选定功能 Added selection funcion of UHF area;

2013-10-17 1) 高频读写器的接口函数全部换成新的版本 The interface functions of HF reader are all replaced with the new version; 2) 14443A标签的加密功能暂时关闭 The encryption function of 14443A tas is disabled temporarily;



ENQUIRY

CONTACT US

Cellphone:
+86-13606915775(John Lee)

Phone:
+86-592-3365735(John)
+86-592-3365675(Cathy)
+86-592-3166853(Margaret)
+86-592-3365715(Anna)
+86-592-3365685(Ellen)
+86-592-3365681(Lynne)

Email: sales@rfidtagworld.com

Add: No.943, Tonglong Er Lu, Hongtang Town, Tong'an District, Xiamen( Xminnov IOT Industrial Park)
