Whole process real-time temperature record
Variety of data read methods including NFC phones
Cold chain information management that consumers can participate in
High accuracy temperature sensoring ± 0.5 degree
With More than 4,000 offline reading & data storage
Temperature Logging interval is customized & flexible
Suitable for healthcare, medical, logistics cold chain supply and warehouse digital transformation
HP200133B NFC Intelligent Temperature Sensor Logger Waterproof Temperature Measure NFC Card HF ABS Card
Tag Dimension: 86*54*3mm (Antenna Size: 46*46mm)
Chip: FM13DT160 (Protocol: ISO14443A & ISO18000-6C GEN2)
Memory: TID/UID 96bit+ EPC/Block 96bits+ User 0-8kbits(total 160kbit EEPROM)+ Reserve 32bits kill & 32bits access
Operating Frequency: 13.0-14.5Mhz
FaceStock/Housing: ABS Plastic Housing
Reading Range: 3cm on Air-Free (Depends on Reader)
Installation: Carry & Band Wearable Style
Characteristic: Temperature Sensor
Feature Option: Free consulting and free samples with solution proposal & evaluation, Fast sampling within 2-3days is provided to support ODM/OEM/SKD in order to meet the customized printing including mono/color barcode and text Embossing, laser-engraving, personalization and encoding service
FM13DT160 Smart Phone APP User Guide
FM13DT160 Temperature Sensor Android DemoApp
FM13DT160 Android APK APP User Manual
FM13DT160 DemoAPP iOS SourceCode
FM13DT160 DemoApp Android SourceCode
FM13DT160 Temperature Sensor Ref to Fudan UHF R2000 Develop SDK
FM13DT160 ISO14443(T2T) Application manual- Customized Function Only
May 20, 2021
1、APP demo DT160 Andorid APP 9.2.9 & source code
2、RTC_FLOW_FLAG=1, register operation at C085 is disable
Feb 4, 2021
Logging data enable to export as Excel format
Temperature sensor card can be attached to the medicine, vaccinum, blood bag, drugs in the hospital to ensure good taking care of the patients.
Prevent mistaken & repeated operation take out/put back items from warehouse, Highly proposed in controlling of Medical drugs, reagents, blood, vaccines inside shipping and storage container such as cold chain transportation.
Resist dangerous operation, allow both of RFID and NFC celllphone are available to be read those temperature records during transacation.
