XMINNOV
The Bluetooth tag's miniaturized design makes installation easy.
Single-channel design simplifies the communication process.
Bluetooth technology can be connected to a variety of smart devices.
Bluetooth LED lights Tag can quickly attract users' attention.
Suitable for warehouse inventory item positioning, shelf positioning.
Product Size: 38(L)*30(W)*13mm(H)
Product Weight: 20g
Battery: CR2477
Communication Protocol: AES encryption private
Frequency : 2.4035GHz
Transmit power: Default 0dBm
Installation: Stick
Housing Material: PC
Communication range: 20-50m(Depending on the environment)
Working hours: 18 months (battery life is calculated based on the frequency of lighting by the customer)
Storage temperature: 0～65℃
color: White and transparent (customizable)
IVF-BT01L tag is a 2.4G custom electronic tag with colorful light reminder. It has 6 colors, a single RGB headlight, a transparent shell, and high brightness. It can quickly find objects in item management (the found items have luminous prompts). It is suitable for application areas such as Cainiao Station cargo, picking of Chinese herbal medicines, finding objects in supermarket warehouses, and finding experimental samples.
Bluetooth communication part: It has a built-in Bluetooth module, which works in a specific Bluetooth frequency band (2.4GHz band). When paired with an external device, it receives instructions from the external device. These instructions are transmitted through the Bluetooth protocol. Single channel means that it receives and sends information on a specific communication path, which can simplify the communication process.
LED control part: There is a simple circuit inside the device to control the on and off and flashing mode of the LED. When receiving specific instructions from the Bluetooth module, the control circuit changes the state of the LED.
